M 81


exposed at January / February 2012


30 % resolution


camera : Atik 383L+
lens: 12 " Newton f/2.95 (ASA reducer/corrector 2 " 0.73x)
filter : Baader LRGB
exposure software : Astroart 5.0
guiding: Pentax 75SDHC with Mintron MTV-12V6HC-EX and Guidemaster

exposure time :

LRGB
L : 115 x 5 min ( 9 hours / 25min )
R : 16 x 5 min ( 1 hour / 20 min )
G : 16 x 5 min ( 1 hour / 20 min )
B : 16 x 5 min ( 1 hour / 20 min )
total: 13 hours and 25 min

location : Home observatory Leopoldshöhe
image processing : Fitswork (image addition, Flat correction) / Astroart 5 / Regim (color calibration and Background processing) / PS CS5 (final processing)
spezifics : -
Bild mit 67 % Auflösung

exposed at January / February 2011


40 % resolution


camera : Alccd6c Pro (QHY8pro)
lens: 12 " Newton f/4 (Baader RCC 1 corrector)
filter : -
exposure software : CCDCap / Gain 20 / Offset 126
guiding: OAG with Mintron MTV-12V6HC-EX and Guidemaster
exposure time : 14 x 10min
location : Home observatory Leopoldshöhe
image processing : Fitswork (image addition, Flat correction) / Regim (color calibration and Background processing) / PS CS3 (final processing)
spezifics : nothing
here you can find the full resolution


aufgenommen am 27.02 sowie 05.03 / 14.03.2008
Lhargb


Lhargb Kerngebiet 200 % vergrößert

Kamera : Atik 16 HR
Objektiv : 12 Zoll f 4,5 Newton
Filter : Baader UV / IR Cut Filter, Astronomik RGB- und 6 NM ha-Filter
Aufnahmeprogramm : Atik Software
Belichtungszeit : L Kanal 330 min (33 mal 10min), ha 10 mal 5min, rgb-Bild 10 mal 5 min 2 fach Binning
Aufnahmeort : Balkonsternwarte Leopoldshöhe
Besonderheiten : Wolkendurchzug bei ha und RGB Bildern

01.02.2005



Kamera : SBig ST7e, Leihgerät von Jörk Strunk
Objektiv : 12 Zoll f 4,5 Newton der Firma AOM
Filter : Baader UV / IR Cut Filter
Aufnahmeprogramm : CCDOps
Belichtungszeit : L 120 min RG jeweils 30min B 40 min
Aufnahmeort : Balkonsternwarte Leopoldshöhe
Besonderheiten : keine

Aufgenommen am 24/25.02.2003



Kamera : OES Alpha Maxi Kaf 401e
Objektiv : Meade 8 Zoll SC
Reducer : Meade Serie 4000 F 3.9 CCD Reducer
Filter : Astronomik IR-Sperrfilter, Hornsche RGB Filter
Aufnahmeprogramm : AMT Version 1.50
Belichtungszeit : 12 * 600 sec. Komposit RGB 10 * 300 sec 2 fach Binning
Bearbeitung : Flatkorrektur,Histogrammangleich
unscharfe Maskierung, Farbanpassung nach Filterkurve
Aufnahmeort : Balkonsternwarte Leopoldshöhe
Besonderheiten : Wenig Dunst, schlechtes Seeing

Aufgenommen am 26.02.2001



Kamera : OES Alpha Maxi Kaf 400
Objektiv : Meade 8 Zoll SC F 6.3
Filter : Kein
Belichtungszeit : 2 * 1800 sec.
Bearbeitung : Histogrammangleich, unscharfe Maske
Aufnahmeort : Balkonsternwarte Leopoldshöhe

exposed March / April 1993


30 % resolution


Kamera : Olympus OM 1
Optik: 10 " Newton f/5
Dia-Film : Kodak TP 2415 hypersen.
Guiding: per Hand am Leitrohr mit GA 4 Nachführeinheit
Belichtungszeit : 45 min
Aufanhemort: meine Gartensternwarte bei meinem Onkel in Helpup

Besonderheiten : die Geschichte zum Bild !!!
Hier ist die Geschichte zum Bild !
