Abell 82 (PN)
exposed at 24.08. and 03.09.2011
CCD picture 50 %
CCD picture Atik 383L+ crop
camera : Atik 383L+
lens: 12 " Newton f/4 (Baader RCC 1 corrector) Atik 383L+
filter : Baader LRGB (ccd)
exposure software : Astroart 5.0
guiding: OAG with Mintron MTV-12V6HC-EX and Guidemaster
exposure time :
LRGB
L : 24 x 10 min ( 4 hours )
R : 9 x 5 min ( 45 min / 2x2 bin )
G : 9 x 5 min ( 45 min / 2x2 bin )
B : 9 x 5 min ( 45 min / 2x2 bin )
total: 6 hours and 15 min
location : Home observatory Leopoldshöhe
image processing : Astroart 5 (stacking/Dark/Flat) / Regim (color calibration and Background processing) / PS CS3 (final processing)
spezifics : -
