IC 1805 03.12.2016
Bild Info
Kamera / Camera :
Luminaz Alccd QHY11
RGB Sony Alpha 7 DSLM selbst modifiziert
Instrument :
zeitgleich / contemporaneous
340mm Hypergraph Primärfokus
300mm Newton
Öffnungsverhältnis / aperture ratio:
1:3.2 / 1:3.8
Gesichtsfeld / Field :
114 x 76 und 104 x 69 Bogenminuten
114 x 76 and 104 x 69 arc-minute
Filter :
QHY 11 Baader Luninanz / Sony A7 Bayermatrix
Einzelbelichtungszeit / Sub-Exposure Time:
17x10min Luminanz / 17x10min RGB Iso 200
Gesamtbelichtungszeit / Total Exposure Time :
170 min L / 170 min RGB - > 340 min
Halbwertsbreite (FWHM) Luminanz: 3.1 Bogensekunden im Summenbild
Aufnahmesoftware / Exposure Software: APT 3.12 / Sony Remotesoftware
Montierung / mount:
Alt 7AD
Nachführung / Guiding :
PHD Guiding Version 2 / ASI 290mm
Aufnahmeort / Location : Sternwarte Leopoldshöhe home observatory Leopoldshöhe
Bildbearbeitung / Image Prozessing : Kalibration Dark / Flatfield Fitswork / PixInsight 1.8
Besonderheiten / Spezifics :
- / -
Objekt Info
Name :
IC 1805
Type :
Emissionsnebel
Informationen:
Simbad info
Objektgröße / Size :
60 x 60 arc minutes
Helligkeit / Brightness (visual) :
6,5 mag
Sternbild / Constellation :
Kassiopeia
Koordinaten / Coordinates :
RA 02h32m56s / DE +61°27'57"
-> Karte Sky-Map.org
gesamtes Bildfeld / entire image field
Gesamtbild 100% / full picture 100 %
->
Ältere Bilder / older Pictures -> Klick....
Mouse over
IC 1805
Ced 6 A/B
Tombaught 4
