M 109


22.11.2011


50 % resolution


amera : Atik 383L+
lens: 12 " Newton f/2.95 (ASA reducer/corrector 2 " 0.73x)
filter : Baader LRGB
exposure software : Astroart 5.0
guiding: Pentax 75SDHC with Mintron MTV-12V6HC-EX and Guidemaster

exposure time :

LRGB
L : 36 x 5 min ( 3 hours )
R : 24 x 2 min ( 48 min / 2x2 bin )
G : 24 x 2 min ( 48 min / 2x2 bin )
B : 24 x 2 min ( 48 min / 2x2 bin )
total: 5 hours and 24 min

location : Home observatory Leopoldshöhe
image processing : Fitswork (image addition, Flat correction) / Astroart 5 / Regim (color calibration and Background processing) / PS CS3 (final processing)
spezifics : -

here you can find the full resolution

exposed at three night in March 2011


40 % resolution


camera : Alccd6c Pro (QHY8pro)
lens: 12 " Newton f/4 (Baader RCC 1 corrector)
filter : -
exposure software : CCDCap / Gain 20 / Offset 126
guiding: OAG with Mintron MTV-12V6HC-EX and Guidemaster
exposure time : 28 x 10 min ( 4 hours and 40 min)
location : Home observatory Leopoldshöhe
image processing : Fitswork (image addition, Flat correction) / Regim (color calibration and Background processing) / PS CS3 (final processing)
spezifics : good Seeing
here you can find the full resolution




Kamera : Atik 16 HR
Objektiv : 12 Zoll f 4,5 Newton
Filter : Baader UV / IR Cut Filter, Astronomik 11 NM ha-Filter
Aufnahmeprogramm : Atik Software
Belichtungszeit : L 50 min, ha 50 min (jeweils 10 min)
Aufnahmeort : Balkonsternwarte Leopoldshöhe
Besonderheiten : Seeing FHWH 2,5, erstes Bild mit Off Axis Guider
